Yamaha MCR-B370D Home audio micro system 30 W Black

An aluminium front panel is complemented perfectly with Piano Black Gloss speakers. Boasting VCCS to prevent unwanted speaker vibration delivers premium Yamaha sound while support for Bluetooth®, digital radio and an optical input provides access to a variety of music and audio sources.

- Bluetooth wireless audio streaming
- Hi-res audio (192 kHz / 24-bit FLAC / WAV) via USB
- Authentic Hi-Fi design and tuning
- Elegant Piano Black Gloss speakers
- DAB / DAB+ / FM tuner (service availability may vary by region)
- High-quality Burr-Brown DAC
- Subwoofer pre-out

Bluetooth Wireless Streaming
Connect wirelessly via Bluetooth for quick and simple audio playback from smartphones and other Bluetooth devices. Whether listening to your favourite music streaming services on your phone or watching videos on your tablet, get the most out of your sound by streaming it to your micro Hi-Fi system.

Hi-res Music from USB
Playback of 192 kHz / 24-bit FLAC and WAV files via USB reflects the Hi-Fi origins of this system. This support offers listeners the ability to experience the best in Hi-Fi listening.

PianoCraft Design
The PianoCraft series has for many years, embodied authentic Hi-Fi performance from a compact unit. Inheriting design philosophies from Yamaha Hi-Fi components ensure quality Hi-Fi performance from any PianoCraft product.

Sophisticated Appearance
The MCR-B370D maintains the design image of Yamaha Hi-Fi components - presenting an extremely high-class, sophisticated appearance.

The centre unit has a front panel made of high-grade aluminium with a hairline finish that looks clean and elegant. Adding this stylish system to your room will enhance not just your listening but your home décor as well.

Elegant Black Piano Gloss Speakers
Reminiscent of a Yamaha piano, the Black Gloss cabinets imbue elegance, musicality and performance.

Matched with the aluminium finish on the centre unit, the MCR-B370D emanates style and performance.

VCCS Vibration Control Cabinet Structure Technology
To prevent unwanted cabinet vibration, Yamaha developed an internal structure called VCCS (Vibration Control Cabinet Structure) that employs strategically placed pieces of a composite material providing excellent vibration isolation performance.

Digital Radio
DAB and DAB+ versions of digital radio offer a large selection of radio stations with high-quality sound.

Other benefits include automatic tuning to available stations and display of information such as station name.

Yamaha MCR-B370D. Type: Home audio micro system, Product colour: Black, Number of optical discs: 1 discs. RMS rated power: 30 W, Speaker type: 2-way, Woofer diameter: 11 cm. Supported radio bands: DAB, FM, Tuner type: Digital. Bluetooth range: 10 m. Headphone connectivity: 6.3 mm

Design
Type	Home audio micro system
Product colour	Black
Optical disc player	Y
Cassette deck	N
Number of optical discs	1 discs
On/off switch	Y
Multimedia
Speaker type	2-way
Number of speakers	2
RMS rated power	30 W
Woofer diameter	11 cm
Tweeter diameter	2.5 cm
Impedance	6 Ω
Signal-to-Noise Ratio (SNR)	84 dB
Peak Music Power Output (PMPO)	40 W
Total Harmonic Distortion (THD)	0.05%
Frequency range	60 - 30000 Hz
Bass reflex	Y
Radio
Supported radio bands	DAB, FM
Tuner type	Digital
Preset stations	Y
Preset stations quantity	30
Network
Wi-Fi	Y
Bluetooth	Y
Bluetooth version	4.2
Bluetooth range	10 m
Ports & interfaces
Apple docking	N
Headphone connectivity	6.3 mm
USB 2.0 ports quantity	1
Headphone outputs	1
AUX in	Y
Subwoofer out	Y
Digital audio optical in	1
Performance
Hi-Fi	Y
MP3 playback	Y
Card reader integrated	N
Disc types supported	CD, CD-R, CD-RW
Playback disc formats	CD audio
Audio formats supported	AAC, AIFF, ALAC, FLAC, MP3, SBC, WAV, WMA
USB direct playback	Y
Ergonomics
Volume control	Rotary
CD player	Y
Power
Power source	AC
Power consumption (standby)	1.3 W
Weight & dimensions
Width	180 mm
Depth	323 mm
Height	118 mm
Weight	2.7 kg
Front speaker width	12.3 cm
Front speaker depth	29.8 cm
Front speaker height	19.2 cm
Front speaker weight	2.2 kg
Main unit dimensions (WxDxH)	180 x 322 x 118 mm
Main unit weight	2.7 kg
Package type	Box
Packaging content
Quantity	1
Remote control included	N
Manual	Y
Other features
Bluetooth profiles	A2DP, AVRCP
