Kingston Technology KC600 mSATA 256 GB Serial ATA III 3D TLC

Hardware-based self-encrypting drive with 3D TLC NAND
Kingston’s KC600 is a full-capacity SSD designed to provide remarkable performance and optimised to provide functional system responsiveness with incredible boot, loading and transfer times. It comes in both 2.5” and mSATA form factors using SATA Rev 3.0 interface with backwards compatibility. The
KC600 utilises the latest 3D TLC NAND technology while supporting a full security suite that includes AES 256-bit hardware encryption, TCG Opal and eDrive. It features read/write speeds of up to 550/520MB/s1 to efficiently store your data up to 2TB2. It’s available in a bundle kit that provides everything you need for a smooth and easy desktop and notebook installation and upgrade.

Kingston Technology KC600. SSD capacity: 256 GB, SSD form factor: mSATA, Read speed: 550 MB/s, Write speed: 500 MB/s, Data transfer rate: 6 Gbit/s, Component for: PC/Laptop

Features
SSD form factor	mSATA
SSD capacity	256 GB
Interface	Serial ATA III
Memory type	3D TLC
NVMe	No
Component for	PC/Laptop
Hardware encryption	Yes
Security algorithms	256-bit AES-XTS
Data transfer rate	6 Gbit/s
Read speed	550 MB/s
Write speed	500 MB/s
Random read (4KB)	90000 IOPS
Random write (4KB)	80000 IOPS
Controller type	SMI SM2259
Mean time between failures (MTBF)	1000000 h
TBW rating	150
Power
Power consumption (read)	1.2 W
Power consumption (write)	2.4 W
Power consumption (average)	0.1 W
Power consumption (idle)	0.08 W
Operational conditions
Operating temperature (T-T)	0 - 70 °C
Storage temperature (T-T)	-40 - 85 °C
Operating vibration	2.17 G
Non-operating vibration	20 G
Weight & dimensions
Width	50.8 mm
Depth	9.8 mm
Height	4.85 mm
Weight	7 g
Logistics data
Harmonized System (HS) code	84717070
