TP-LINK AC1200 Wireless Dual Band 4G LTE Router

4G LTE with AC1200 Wi-Fi to Stream from Everywhere
AC1200 Wireless Dual Band 4G LTE Router
Archer MR400

Got SIM Card?
Then Plug and Play!
With an integrated 4G LTE modem and a built-in SIM card slot, all you need to do is insert a micro SIM card and turn on the Router. Enjoying fast, stable Wi-Fi on a 4G LTE network has never been easier.

Share Your 4G LTE Network
Take full of advantage of your cutting-edge 4G LTE network for download speeds of up to 150 Mbps. Share your 4G LTE network with multiple Wi-Fi devices and enjoy uninterrupted HD movies, rapid file downloads, and smooth video chats. Fully compatible with FDD-LTE and TDD-LTE to work with most service providers worldwide.

Wi-Fi Where You Need It
Enjoy unmatched convenience and versatility. Tested in the field for years to ensure universal compatibility with 2 advanced LTE antennas to deliver a smooth connection. Simply plug in a micro SIM card and power on this elegant piece of technology to utilize fast and stable Wi-Fi, whether you’re at home or working remote.

Internet Access for
up to 64 Devices Simultaneously
Easily share a 3G/4G connection with up to 64 wireless devices, such as phones, tablets, and laptops, at the same time. 4 LAN ports stand ready to provide internet for wired devices like desktop computers.

Easy Setup and Management
Set up the Archer MR400 in minutes thanks to its intuitive web interface and the powerful Tether app. Tether also lets you manage its network settings from any Android or iOS device, including parental controls and access control.

TP-LINK AC1200 Wireless Dual Band 4G LTE Router. WAN connection type: RJ-45. Wi-Fi band: Dual-band (2.4 GHz / 5 GHz), Top Wi-Fi standard: Wi-Fi 5 (802.11ac), WLAN data transfer rate (max): 867 Mbit/s. Ethernet LAN interface type: Fast Ethernet, Ethernet LAN data rates: 10,100 Mbit/s, Cabling technology: 10/100Base-T(X). Mobile network generation: 4G, 2G standards: Edge, GPRS, GSM, 3G standards: DC-HSPA+,HSPA,HSPA+,UMTS. Security algorithms: 64-bit WEP,128-bit WEP,WPA,WPA-PSK,WPA2,WPA2-PSK

WAN connection
Ethernet WAN	Y
DSL WAN	N
SIM card slot	Y
3G/4G USB modem compatibility	N
WAN connection type	RJ-45
Wireless LAN features
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	867 Mbit/s
Wi-Fi standards	802.11a,Wi-Fi 5 (802.11ac),802.11b,802.11g,Wi-Fi 4 (802.11n)
WLAN data transfer rate (first band)	450 Mbit/s
WLAN data transfer rate (second band)	867 Mbit/s
Network
Ethernet LAN	Y
Ethernet LAN interface type	Fast Ethernet
Ethernet LAN data rates	10,100 Mbit/s
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11a,IEEE 802.11ac,IEEE 802.11b,IEEE 802.11g,IEEE 802.11n
Port forwarding	Y
Dynamic DNS (DDNS)	Y
VPN tunnels quantity	10
VPN Passthrough	Y
VPN support	PPTP, L2TP, IPSec
Receiver sensitivity	5GHz: 11a 54M: -74dBm 11ac HT20: -67dBm 11ac HT40: -64dBm 11ac HT80 : -60dBm 11n HT20: -71dBm 11n HT40: -70dBm 2.4G: 11g 54M: -76dBm 11n HT20: -73dBm 11n HT40: -67dBm
Mobile network
Mobile network generation	4G
4G	Y
2G standards	Edge, GPRS, GSM
3G standards	DC-HSPA+,HSPA,HSPA+,UMTS
4G standard	LTE
4G bands supported	800,900,1800,2100,2600 MHz
Ports & interfaces
Ethernet LAN (RJ-45) ports	3
USB port	N
Memory card slot(s)	N
DC-in jack	Y
Management features
Web-based management	Y
Quality of Service (QoS) support	Y
Reset button	Y
WPS push button	Y
Security
Security algorithms	64-bit WEP,128-bit WEP,WPA,WPA-PSK,WPA2,WPA2-PSK
Firewall	Y
Access Control List (ACL)	Y
Stateful Packet Inspection (SPI)	Y
DoS attack prevention	Y
DMZ support	Y
Protocols
DHCP client	Y
DHCP server	Y
Supported network protocols	IPv4, IPv6
Design
Product type	Tabletop router
Product colour	Black
Wall mountable	Y
LED indicators	LAN, Power, Status, WLAN
On/off switch	Y
Antenna
Antenna type	Internal & external
Antennas quantity	2
Detachable antenna(s)	Y
Transmit power	CE: <20dBm(2.4GHz), <23dBm(5GHz)
Features
Certification	CE, RoHS
Power
Power source type	DC
Output voltage	12 V
Output current	1.5 A
Operational conditions
Storage relative humidity (H-H)	5 - 90%
System requirements
Windows operating systems supported	Windows 10,Windows 2000,Windows 7,Windows 8,Windows 8.1,Windows 98SE,Windows NT,Windows Vista,Windows XP Home,Windows XP Home x64,Windows XP Professional,Windows XP Professional x64
Linux operating systems supported	Y
Mac operating systems supported	macOS
Mac compatibility	Y
Weight & dimensions
Height	33.5 mm
Packaging data
Cables included	LAN (RJ-45)
AC adapter included	Y
Quick installation guide	Y
Package width	307 mm
Package depth	223 mm
Package height	70 mm
Package type	Box
