TP-Link 300Mbps Wireless N ADSL2+ Modem Router

Bringing Stability and Strength to Your Home Network
300Mbps Wireless N ADSL2+ Modem Router.

All-in-One Device with Stronger Wi-Fi
Combined with ADSL2+ modem and NAT Router, TD-W8961N is an incredibly robust all-in-one device that provides a full rate of ADSL2+ /ADSL2 /ADSL standard with the superb reliability and a cost-effective solution for home and small business.

Wi-Fi Speed Up to 300Mbps
With 300Mbps wireless speeds on the 2.4GHz band and 4 Fast Ethernet LAN ports, TD-W8961N is perfect for streaming in HD, online gaming and other bandwidth-intensive applications.

Powerful Antennas
Two external 5dBi high-gain antennas transmit signal to every corner of your home, creating a strong, stable Wi-Fi network.

WPS Button
Instantly connect your devices to the router without entering the password.

Quick Setup and
Easy Management
Simply follow the intuitive web interface to get setup done in seconds and manage your home network easily.

Advanced Security
SPI Firewalls and WPA2 encryption ensure your wireless connection is safe from intruders.

TP-Link 300Mbps Wireless N ADSL2+ Modem Router. Wi-Fi band: Single-band (2.4 GHz), Top Wi-Fi standard: Wi-Fi 4 (802.11n), WLAN data transfer rate (max): 100 Mbit/s. Ethernet LAN interface type: Fast Ethernet, Ethernet LAN data rates: 10,100 Mbit/s, Cabling technology: 10/100Base-T(X). Security algorithms: 64-bit WEP, 128-bit WEP, WPA-PSK, WPA2-PSK. Supported network protocols: ATM Forum UNI3.1/4.0, PPP over ATM (RFC 2364), PPP over Ethernet (RFC2516), IPoA (RFC1577/2225),.... Product type: Tabletop router, Product colour: Grey, White

WAN connection
Ethernet WAN	Y
SIM card slot	N
3G/4G USB modem compatibility	N
Wireless LAN features
Wi-Fi band	Single-band (2.4 GHz)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	100 Mbit/s
Network
Ethernet LAN	Y
Ethernet LAN interface type	Fast Ethernet
Ethernet LAN data rates	10,100 Mbit/s
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.3, IEEE 802.3u
Mobile network
4G	N
DSL features
ADSL	Y
ADSL2	Y
ADSL2+	Y
Ports & interfaces
Ethernet LAN (RJ-45) ports	4
USB port	N
RJ-11 ports quantity	1
Memory card slot(s)	N
Management features
Quality of Service (QoS) support	Y
Security
Security algorithms	64-bit WEP, 128-bit WEP, WPA-PSK, WPA2-PSK
Protocols
DHCP client	Y
Supported network protocols	ATM Forum UNI3.1/4.0, PPP over ATM (RFC 2364), PPP over Ethernet (RFC2516), IPoA (RFC1577/2225), PVC - Up to 8 PVCs
Design
Product type	Tabletop router
Product colour	Grey, White
Antenna
Antenna design	External
Antenna gain level (max)	5 dBi
Transmit power	20 dBmW
Features
Certification	CE, FCC, RoHS
Power
Power source type	DC
Output voltage	9 V
Output current	0.6 A
Operational conditions
Storage relative humidity (H-H)	5 - 90%
System requirements
Windows operating systems supported	Windows 2000, Windows 2000 Professional, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows 98SE, Windows NT, Windows Vista, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows Vista x64, Windows XP, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Linux operating systems supported	Y
Mac operating systems supported	Y
Mac compatibility	Y
Weight & dimensions
Height	35 mm
Packaging data
Package width	285 mm
Package depth	232 mm
Package height	70 mm
Package weight	590 g
Package type	Box
Number of products included	1 pc(s)
Logistics data
Harmonized System (HS) code	85176990
