D-Link DAP-3315 wireless access point 300 Mbit/s White Power over Ethernet (PoE)

The DAP-3315 Wireless N Exterior Access Point is the ideal solution for expanding the coverage and signal strength of any wireless network. Built to withstand harsh environments, the DAP-3315 also excels in connecting separate networks that cannot be joined physically using traditional medium. Multiple operating modes, network management tools, and security features gives network administrators a wide range of choices for deploying the device, allowing for the addition of increased connectivity to wireless network-enabled devices.

Increased Network Connectivity And Throughput

Expand current wireless network capacity with the latest 2.4 GHz 802.11n wireless connectivity. In addition, two 10/100 Ethernet ports (one supporting PoE) allow for further physical expansion using traditional wired medium. The built-in 12 dBi sector antenna has a high power output ensuring that wireless coverage will cover even hard to reach locations. Whether you want to connect additional wireless devices such as smartphones or laptops, or bringing connectivity to networks separated by short distances, the DAP-3315 has it covered.

Flexible Deployment Options

The DAP-3315 features seven multiple operation modes, allowing it to adapt to any situation. As a standard wireless access point (AP) the DAP-3315 can connect to a wide range of devices that are 802.11n/g/b compliant. In wireless distribution system (WDS) mode it can expand current wireless coverage without the need for a wired backbone link .As a wireless client it can connect to an existing AP and expand the network physically with the two built-in 10/100 Ethernet ports. Repeater mode will extend current wireless coverage eliminating dead spots and weak signals. WISP mode functionality includes the ability to function as a client or repeater.

Fine-Tuned Control Over Network Resources.

The DAP-3315 supports up to 8 SSIDs, allowing the administrators to logically divide the access point into several virtual access points all within a single hardware platform. Rather than having separate networks with several access points, administrators can deploy one single AP to support more than one application, such as public Internet access and internal network control to increase flexibility and keep costs down. The DAP-3315 supports 802.1Q VLAN Tagging, operating with multiple SSIDs to segment traffic to enhance performance and security. The DAP-3315 provides WLAN partitioning, a useful function for deployments such as wireless hot spots. With station-to-station partitioning enabled, security is enhanced, since wireless users cannot peek at each other, and the possibility for data theft is reduced.

Robust Security and Management Tools

The DAP-3315 supports 64/128-bit WEP data encryption and WPA/WPA2 security functions. In addition, it provides MAC Address Filtering to control user access, and the Disable SSID Broadcast function to limit outsiders access to the internal network. Network administrators have multiple options for managing the DAP-3315 including HTTP and HTTPS.

Power over Ethernet (PoE)*

The DAP-3315 is powered by PoE which allows for convenient installation, especially in places where a power supply is not reliable or power cables are not available or easily set up

D-Link DAP-3315. Maximum data transfer rate: 300 Mbit/s, Wi-Fi data rate (max): 300 Mbit/s, Ethernet LAN data rates: 10,100 Mbit/s. Security algorithms: 64-bit WEP, 128-bit WEP, 802.1x RADIUS, WPA, WPA-Enterprise, WPA2, WPA2-Enterprise. Management protocols: HTTP (HTTPS). AC input voltage: 24 V, Input current: 0.5 A. Product colour: White, LED indicators: LAN, Power, Signal strength, Certification: CE, FCC

Features
2.4 GHz	Yes
5 GHz	No
Maximum data transfer rate	300 Mbit/s
Wi-Fi data rate (max)	300 Mbit/s
Ethernet LAN data rates	10,100 Mbit/s
Networking standards	IEEE 802.3, IEEE 802.3u
Security
Security algorithms	64-bit WEP, 128-bit WEP, 802.1x RADIUS, WPA, WPA-Enterprise, WPA2, WPA2-Enterprise
MAC address filtering	Yes
Number of SSID supported	8
Protocols
Management protocols	HTTP (HTTPS)
Ports & interfaces
Ethernet LAN (RJ-45) ports	2
Power
Power over Ethernet (PoE)	Yes
AC input voltage	24 V
Input current	0.5 A
Design
Product colour	White
Reset button	Yes
LED indicators	LAN, Power, Signal strength
Certification	CE, FCC
Internal	No
Antenna
Antennas quantity	1
Antenna gain level (max)	12 dBi
Weight & dimensions
Width	118 mm
Depth	56 mm
Height	195 mm
Weight	303 g
Packaging data
Package width	260 mm
Package depth	265 mm
Package height	70 mm
Package weight	997 g
Operational conditions
Operating relative humidity (H-H)	10 - 90%
Operating temperature (T-T)	-20 - 60 °C
Storage temperature (T-T)	-20 - 85 °C
Storage relative humidity (H-H)	5 - 95%
Logistics data
Harmonized System (HS) code	85176990
