Garanzia3 Gr3V500 3-Year Extended Warranty Coverage for Products up to €500
TP-Link 16-Port Gigabit Easy Smart Switch with 8-Port PoE+, Managed, L2, Gigabit Ethernet (10/100/1000), Power over Ethernet (PoE), Rack mounting, 1U
TP-Link 16-Port Gigabit Easy Smart Switch with 8-Port PoE+
€197.91 Tax included
Article Code: 597562
New product
2-Year Italian Warranty:
TP-Link 16-Port Gigabit Easy Smart Switch with 8-Port PoE+, Managed, L2, Gigabit Ethernet (10/100/1000), Power over Ethernet (PoE), Rack mounting, 1U
What This Product Does
The TL-SG1016PE is an 16-Port Gigabit Desktop/Rack mountable Switch with 8 ports supporting the PoE+ standard. It provides a simple way to expand a wired network by transferring power and data over a single Ethernet Cable. With a total power budget of 110W, up to 30W per port, TL-SG1016PE can power more high-powered devices such as wireless Access Points (APs), IP Cameras or IP Phones. Moreover, with innovative energy-efficient technology, the TL-SG1016PE can save up to 75% of the power consumption, making it an eco-friendly solution for your business network.
TP-Link 16-Port Gigabit Easy Smart Switch with 8-Port PoE+. Switch type: Managed, Switch layer: L2. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 16. MAC address table: 8000 entries, Switching capacity: 32 Gbit/s. Networking standards: IEEE 802.1Q, IEEE 802.1p, IEEE 802.3ab, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x. Power connector: AC-in jack. Power over Ethernet (PoE). Rack mounting, Form factor: 1U
The TL-SG1016PE is an 16-Port Gigabit Desktop/Rack mountable Switch with 8 ports supporting the PoE+ standard. It provides a simple way to expand a wired network by transferring power and data over a single Ethernet Cable. With a total power budget of 110W, up to 30W per port, TL-SG1016PE can power more high-powered devices such as wireless Access Points (APs), IP Cameras or IP Phones. Moreover, with innovative energy-efficient technology, the TL-SG1016PE can save up to 75% of the power consumption, making it an eco-friendly solution for your business network.
TP-Link 16-Port Gigabit Easy Smart Switch with 8-Port PoE+. Switch type: Managed, Switch layer: L2. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 16. MAC address table: 8000 entries, Switching capacity: 32 Gbit/s. Networking standards: IEEE 802.1Q, IEEE 802.1p, IEEE 802.3ab, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x. Power connector: AC-in jack. Power over Ethernet (PoE). Rack mounting, Form factor: 1U
| Caratteristiche di gestione | |
| Tipo interruttore | Gestito |
| Livello del commutatore | L2 |
| Supporto qualità del servizio (QoS) | Sì |
| Gestione web-based | Sì |
| Connettività | |
| Quantità di porte RJ-45 | 16 |
| Tipo di porte RJ-45 | Gigabit Ethernet (10/100/1000) |
| Quantità di porte Gigabit Ethernet (rame) | 16 |
| Connettore di alimentazione | Jack di ingresso AC |
| Collegamento in rete | |
| Standard di rete | IEEE 802.1Q, IEEE 802.1p, IEEE 802.3ab, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x |
| Supporto 10G | No |
| Tecnologia Ethernet su cavi in rame | 10BASE-T, 100BASE-TX, 1000BASE-T |
| Tipi di cavi supportati | Cat3, Cat4, Cat5, Cat5e, Cat6 |
| Mirroring della porta | Sì |
| Auto-negoziazione | Sì |
| VLAN support | Sì |
| Caratteristiche della LAN virtuale | Tagged VLAN, Port-based VLAN |
| Numero di VLA | 4000 |
| Trasmissione dati | |
| Dimensioni tavola MAC | 8000 voci |
| Capacità di commutazione | 32 Gbit/s |
| tasso di inoltro | 23,8 Mpps |
| Store-and-forward | Sì |
| Numero di code | 4 |
| Supporto Jumbo Frames | Sì |
| Frame Jumbo | 10000 |
| Buffer di memoria di pacchetto | 4,1 MB |
| Sicurezza | |
| Funzione IGMP snooping | Sì |
| Design | |
| Montaggio rack | Sì |
| Impilabile | No |
| Fattore di forma | 1U |
| Colore del prodotto | Nero |
| Materiale della scocca | Metallo |
| Indicatori LED | Sì |
| Numero di ventole | 1 ventola(e) |
| Prestazione | |
| lunghezza massima cavo | 100 m |
| Gestione energetica | |
| Alimentazione | AC/PoE |
| Fonte di alimentazione inclusa | Sì |
| Tensione di ingresso AC | 100 - 240 V |
| Frequenza di ingresso AC | 50/60 Hz |
| Consumo energetico (max) | 124,4 W |
| Power over Ethernet (PoE) | |
| Supporto Power over Ethernet (PoE) | Sì |
| Quantità di porte Power over Ethernet plus (PoE+) | 8 |
| Potenza Power over Ethernet (PoE) per porta | 30 W |
| Bilancio energetico totale del PoE | 110 W |
| Condizioni ambientali | |
| Intervallo temperatura di funzionamento | 0 - 40 °C |
| Intervallo di temperatura | -40 - 70 °C |
| Range di umidità di funzionamento | 10 - 90% |
| Umidità | 5 - 90% |
| Dimensioni e peso | |
| Larghezza | 294 mm |
| Profondità | 180 mm |
| Altezza | 44 mm |
| Sostenibilità | |
| Conformità alla sostenibilità | Sì |
Informazioni sul produttore
TP-Link Technologies Co., Ltd.
Zeestraat 1
2201 AZ - Noordwijk
Paesi Bassi
CONTATTI
Tel: +31 71 889 1199
Mail: support.eu@tp-link.com
____
Persona responsabile dell’UE
Operatore economico con sede nell’UE che garantisce la conformità del prodotto alle normative richieste.
TP-Link Technologies Co., Ltd.
Zeestraat 1
2201 AZ - Noordwijk
Paesi Bassi
Data sheet
- Width
- 294 mm
- Depth
- 180 mm
- Height
- 44 mm
- Package width
- 250 mm
- Package depth
- 400 mm
- Package height
- 80 mm
- Package weight
- 2.28 kg
- Product colour
- Black
- Operating temperature (T-T)
- 0 - 40 °C
- Storage temperature (T-T)
- -40 - 70 °C
- Cables included
- AC
- Power source
- AC/PoE
- Package type
- Box
- AC input voltage
- 100 - 240 V
- Housing material
- Metal
- AC input frequency
- 50/60 Hz
- Networking standards
- IEEE 802.1Q, IEEE 802.1p, IEEE 802.3ab, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x
- LED indicators
- Yes
- Operating relative humidity (H-H)
- 10 - 90%
- Storage relative humidity (H-H)
- 5 - 90%
- Sustainability compliance
- Yes
- Switch type
- Managed
- Switch layer
- L2
- Quality of Service (QoS) support
- Yes
- Web-based management
- Yes
- Basic switching RJ-45 Ethernet ports quantity
- 16
- Power connector
- AC-in jack
- Copper ethernet cabling technology
- 10BASE-T, 100BASE-TX, 1000BASE-T
- Port mirroring
- Yes
- Flow control support
- Yes
- Link aggregation
- Yes
- Broadcast storm control
- Yes
- Auto MDI/MDI-X
- Yes
- Number of VLANs
- 4000
- MAC address table
- 8000 entries
- Switching capacity
- 32 Gbit/s
- Store-and-forward
- Yes
- Packet buffer memory
- 4.1 MB
- IGMP snooping
- Yes
- Rack mounting
- Yes
- Stackable
- No
- Power over Ethernet (PoE)
- Yes
- User guide
- Yes
- VLAN support
- Yes
- Form factor
- 1U
- Power consumption (max)
- 124.4 W
- Basic switching RJ-45 Ethernet ports type
- Gigabit Ethernet (10/100/1000)
- 10G support
- No
- Jumbo frames support
- Yes
- Jumbo frames
- 10000
- Power supply included
- Yes
- Power over Ethernet plus (PoE+) ports quantity
- 8
- Total Power over Ethernet (PoE) budget
- 110 W
- Rack mount kit
- Yes
- Compatible operating systems
- Windows
- Gigabit Ethernet (copper) ports quantity
- 16
- Virtual LAN features
- Tagged VLAN, Port-based VLAN
- Forwarding rate
- 23.8 Mpps
- Number of fans
- 1 fan(s)
- Auto-negotiation
- Yes
- Resource CD
- Yes
- Cable types supported
- Cat3, Cat4, Cat5, Cat5e, Cat6
- Power over Ethernet (PoE) power per port
- 30 W
- Compliance certificates
- CE, Federal Communications Commission (FCC), RoHS
- Number of queues
- 4
- Maximum cable length
- 100 m
