TEAC TN-4D-SE Direct drive audio turntable Walnut Manual

A sleek motor, developed exclusively for direct-drive turntables
The TN-4D-SE uses a sleek, brushless DC motor, offering crystal-locked speed accuracy, regulated by a computer-controlled feedback circuit and achieving low wow-and-flutter levels for a direct drive turntable, especially one with such a stylish, low-profile design.

Knife-edge, pivot-point tone-arm bearings
In collaboration with SAEC Corporation, a world-famous, high-end tonearm manufacturer, the TN-4D-SE's tonearm employs a knife-edge, pivot-point bearing. Unlike the case for tonearms with conventional bearings, any fine vertical movements encountered by this tonearm actually help in delivering a more dynamic sound with excellent resolution. The S-shaped tonearm also employs a universal headshell fitting, allowing users to quickly and easily swap cartridges/headshells, and supports a wide range of cartridge weights (from 14 - 23g / 0.5 - 0.8 oz.)

Precision anti-skating and stylus-pressure adjustment
As you might expect, the tonearm is equipped with a counterweight, for precise stylus-pressure adjustment, and an anti-skating mechanism.

Pre-installed Oyster cartridge by SUMIKO
The TN-4D-SE comes with a well-regarded Oyster MM cartridge from SUMIKO – a legendary American cartridge manufacturer. Regardless of the type of music, the Oyster cartridge delivers a powerful but insightful performance.

Built-in PHONO EQ amplifier supporting MM cartridges
The TN-4D-SE comes with a built-in PHONO EQ amplifier that allows you to directly connect the turntable to the line-level inputs of your existing hi-fi system. The NJM8080 IC from New Japan Radio Corporation is employed for op-amp duties, bringing up the level of the tiny signals received via the cartridge up to LINE level strength without any loss of quality.

Die-cast aluminium platter
In conjunction with the newly-developed motor, the high inertia, die-cast aluminium platter helps to achieve better speed stability.

Insulating feet with excellent shock absorption

The insulating feet comprise a machined aluminium shell topped with a rubber cushion that is fixed to the high-density MDF plinth. Thanks to their excellent shock absorption characteristics the TN-4D-SE is very resistant to acoustic feedback.

2-speed turntable for 33-⅓ and 45 rpm
The TN-4D-SE supports 33-⅓ and 45 rpm for LP and EP records. Our insistence on quality engineering can even be seen in the construction of the rotary control for start-up/speed selection, formed of machined aluminium.

TEAC TN-4D-SE. Type: Direct drive audio turntable, Operation: Manual, Product colour: Walnut. Tonearm type: Statically balanced tonearm, Shape: S-shaped tonearm, Arm length: 22.3 cm. Power supply type: AC, Power consumption (typical): 2 W, Power consumption (standby): 0.5 W. Width: 420 mm, Depth: 356 mm, Height: 117 mm. Cables included: RCA

Caratteristiche
Tipo	Giradischi a trasmissione diretta
Operazione	Manuale
Colore del prodotto	Noce
Materiale della scocca	Alluminio
materiale piatto	Alluminio
Velocità nominali	33 1/3,45 Giri/min
Tipo di spazzola per motore	Senza spazzola
Tipo di cartuccia	MM-type (VM-type)
Prodotti compatibili	Styluses for SUMIKO Oyster
Braccio
Tipo di braccio	Braccio bilanciato staticamente
Forma	Braccio a S
Lunghezza supporto	22,3 cm
Connettività
Uscite della linea (RCA)	2
Gestione energetica
Adattatore di frequenza AC	50/60 Hz
Dimensioni e peso
Larghezza	420 mm
Profondità	356 mm
Altezza	117 mm
Peso	6,1 kg
diametro del piatto	30 cm
Contenuto dell'imballo
Quantità	1
Contrappeso	Sì
